    7Kw Auxiliary Machinery UV Curing Equipment For Cylindrical / Oval / Flat Bottles

    Ask Lasest Price
    Brand Name : SX
    Model Number : SX
    Certification : CE
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 10 Set One Month
    Delivery Time : 10 Days After Receiving Down Payment In Advance
    • Product Details
    • Company Profile

    7Kw Auxiliary Machinery UV Curing Equipment For Cylindrical / Oval / Flat Bottles

    7Kw Auxiliary Machinery UV Curing Equipment For Cylindrical / Oval / Flat Bottles


    Description:

    It is mainly used for the drying of cylindrical/oval/flat bottles, sheets, containers which are printed by screen printing.
    The machine size can be customized according to product.

    Specifications:

    1. Max product width: 400mm
    2. Max product length:320mm
    3. Printing speed :1800~3000Pic/Hr
    4. Conveyer speed: 0-10m/min
    5. UV lamp power:5Kw
    6. Total power: 7Kw
    7. Power supply :AC 380V/ 50Hz 3-Phase
    8. Machine size:(LxWxH)2100x750x1810mm
    9. Machine weight:353Kg
    10. Packing Size:245*83*192CM
    Advantages:

    1. Suitable for the UV Ink printing cure on round,oval,flat bottles and cylindrical substrate.
    2. By adjusting its lighting angle, it can also be used in the UV ink printing cure of flat or curved substrate;
    3. Enclosure construction with conveyor. Apply half light (3KW) or full light (6KW) tubes, the distance is adjustable;
    4. On the top of the machine equipped with an exhaust system, you can vent the inside heat of curing chamber .
